Hose Reel
30-metre rubber fire hose reels in swing, drum, and recessed cabinet types. 19mm/25mm bore with manual or automatic shut-off valve. Easy to operate without special training for early-stage fire control.
Hose Length
30 metres
Hose Bore
19mm / 25mm
Operating Pressure
0.2–1.4 MPa
Hose Reel
IS:884 / IS:8423
Working Principle
How It Works
A hose reel provides a continuous 30-metre supply of water from the building's internal hydrant ring main or direct water supply. The reel unwinds as the operator moves toward the fire — no need to carry heavy coils of hose. Opening the shut-off valve at the nozzle end starts the water flow. The 19mm bore produces a jet sufficient to control small to medium fires from a safe 3–5 metre distance without specialist training.
Product Range
Available Types & Variants
What You Get
Key Features
Use Cases
Where It's Used
At a Glance
Technical Specifications
Hose Length
30 metres
Hose Bore
19mm / 25mm
Operating Pressure
0.2–1.4 MPa
Nozzle Type
Straight-bore jet / spray
Certification
IS:884 / IS:8423
Keep It Ready
Maintenance & AMC Tips
Monthly operational test — unwind fully and check water flow
Inspect hose for cracks, blisters, or kinks annually
Lubricate reel spindle and valve gland packing annually
Check wall bracket fixings and cabinet door hinges
Verify connection to ring main or water supply is open and pressurised
Legal & Compliance Requirement
Hose reels are specified in IS:884 and NBC 2016 for all buildings with hydrant systems. They serve as the first line of water-based defence for occupants before fire brigade arrival and can be operated without specialist training. Fire NOC inspections verify hose reel installation at required spacings — typically one per 800 m² of floor area.
Get Hose Reel for Your Premises
Contact our fire safety engineers for a free site visit, product demonstration, and customised quote — no obligation.
